Model comparison
Models
Lapis 2026
Santa Maria E-Gravel
Santa Maria E-Road
Mica G
Quartz 2026
Peridot 2026
Quartz SUV 2026
Marble SUV 2026
Turmali M/L 2026
Quartz M 2026
Turmali S 2026
Mica Pro 2026
Dolomit 2026
Turmali Comfort 2026
Technical information
Type
field of application.
Color variations
engine type
torque
Power
Sensors
Support levels
Reach
battery capacity
Charging time
Fork
Tires
Drive
Brake system
Front Lights
Rear Light
Net weight
Frame type
Size
stride
Max. permissible total weight
frame material
Rack
Display
App
| Technical information |
Lapis 2026
|
Santa Maria E-Gravel
|
Santa Maria E-Road
|
Mica G
|
Quartz 2026
|
Peridot 2026
|
Quartz SUV 2026
|
Marble SUV 2026
|
Turmali M/L 2026
|
Quartz M 2026
|
Turmali S 2026
|
Mica Pro 2026
|
Dolomit 2026
|
Turmali Comfort 2026
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ebike Model |
€3.299,00
|
€3.499,00
|
€3.499,00
|
€1.999,00
|
€1.399,00
|
€1.699,00
|
€1.599,00
|
€1.699,00
|
1.699,00 € – €1.899,00
|
€1.399,00
|
1.599,00 € – €1.799,00
|
€2.799,00
|
€2.399,00
|
€1.899,00
|
| Type | SUV | Road/Gravel | Road/Gravel | Trekking | City | Folding | SUV | SUV | Urban | City | Urban | SUV | MTB | Urban |
| field of application. | Commuting & Off-road | gravel paths | Driving fast | Long-distance tours | Commuting & Shopping | Commuting & Travel | Commuting & Off-road | Commuting & Off-road | Urban Transport & Mobility | Commuting & Everyday Life | Urban Transport & Mobility | Commuting & Off-road | Off-road and mountain driving | Urban Transport & Mobility & Comfort |
| Color variations | Cumbrian green | Obsidian Black, Skyscraper Gray | Sakura Pink, Skyscraper Grey | Moonbeam, Royal Ebony matt | Moonbeam, Titan Grey Matt, City Leaf | Dark Graphite, Mineral White, Tanzanite Blue | Sage Green Gloss, Volcanic Black | Light Truffle Brown | Yves Klein Blue, Black Opal, Signature Black, Airy Blue | Metallic Gray | Cream White, Shade Green, Airy Blue | Silk Chiffon, Bronze Matte | Black Mirage, Drizzle Green | Almond White, Golden Hour Orange |
| engine type | mid-engine | Integrated motor hub | Integrated motor hub | mid-engine | Integrated motor hub | Integrated motor hub | Integrated motor hub | Integrated motor hub | Integrated motor hub | Integrated motor hub | Integrated motor hub | mid-engine | mid-engine | Integrated motor hub |
| torque | 110 Nm | 30 Nm | 30 Nm | 80 Nm | 55 Nm | 55 Nm | 55 Nm | 55 Nm | 35 / 40 Nm | 55 Nm | 35 / 40 Nm | 110 Nm | 110 Nm | 35 / 40 Nm |
| Power | 250 W | 250 W | 250 W | 250 W | 250 W | 250 W | 250 W | 250 W | 250 W | 250 W | 250 W | 250W (Max 900W) | 250W (Max 900W) | 250 W |
| Sensors | Cadence and torque sensor | Cadence and torque sensor | Cadence and torque sensor | Cadence and torque sensor | Cadence and torque sensor | cadence sensor | Cadence and torque sensor | Cadence and torque sensor | Cadence and torque sensor | cadence sensor | Cadence and torque sensor | Cadence and torque sensor | Cadence and torque sensor | Cadence and torque sensor |
| Support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 5 support levels | 6 support levels including auto mode | 6 support levels including auto mode | 5 support levels |
| Reach | Up to 161 km | Up to 90 km | Up to 90 km | Up to 161 km | Up to 161 km | Up to 143 km | Up to 161 km | Up to 161 km | Up to 110 km | Up to 121 km | Up to 110 km | Up to 180 km | Up to 180 km | Up to 110 km |
| battery capacity | 644 Wh | 252 Wh | 252 Wh | 644 Wh | 644 Wh | 500 Wh | 644 Wh | 644 Wh | 360 Wh | 483 Wh | 360 Wh | 720 Wh | 720 Wh | 360 Wh |
| Charging time | 6-7 Std. | 3-4 Std. | 3-4 Std. | 6-7 Std. | 6-7 Std. | 5-6 Std. | 6-7 Std. | 6-7 Std. | 2,5 Std. | 6-7 Std. | 2,5 Std. | 5 Std. | 5 Std. | 2,5 Std. |
| Fork | RockShox Judy Air, 100 mm | Deruiz Carbon Fork | Deruiz Carbon Fork | Suntour NEX-E25, 75 mm | Deruiz suspension fork, 60 mm | Deruiz suspension fork, 60 mm | SR Suntour XCM32, 100 mm | SR Suntour XCM32, 100 mm | Deruiz aluminum fork | SR Suntour NEX, 63 mm | Deruiz aluminum fork | Suntour XCM34 Boost, 100 mm | SR Suntour XCM34 Boost, 120mm | SR Suntour NEX-E25, 63 mm |
| Tires | Schwalbe Hurricane 27.5" | Continental Terra Trail 40C | Schwalbe E-One 32C | Schwalbe Green Marathon 28" | Schwalbe Road Cruiser 28 | Chaoyang 20 × 3.0 | Schwalbe Smart Sam 27.5 | Schwalbe Smart Sam 27.5" | Schwalbe G-One RS 45C | Schwalbe Big Ben 28" | Schwalbe G-One RS 45C | Schwalbe Johnny Watts 365 S/M: 27,5 |
Schwalbe Smart Sam 29" | Schwalbe Big Apple 28 |
| Drive | Shimano Deore, 10-speed | SRAM Rival 1, 11-speed | SRAM Rival 1, 11-speed | Shimano Altus, 9-speed | Shimano Altus, 8-speed | Shimano Altus, 8-speed | Shimano Acera, 8-speed | Shimano Acera, 8-speed | Belt drive: Gates CDN Chain drive: Shimano Deore, 10-speed |
Shimano Altus, 8-speed | Belt drive: Gates CDN Chain drive: Shimano Deore, 10-speed |
Enviolo CVT | Shimano CUES, 11-speed | Belt drive: Gates CDN Chain drive: Shimano CUES, 9-speed |
| Brake system | Tektro Gemini hydraulic disc brakes | SRAM Rival hydraulic disc brakes | SRAM Rival hydraulic disc brakes | Tektro hydraulic disc brakes | Hydraulic disc brakes | GA-950E hydraulic disc brakes | Tektro hydraulic disc brakes | Tektro hydraulic disc brakes | Tektro hydraulic disc brakes | Mechanical disc brakes | Tektro hydraulic disc brakes | Shimano / Tektro hydraulic disc brakes | Shimano / Tektro hydraulic disc brakes | Tektro hydraulic disc brakes |
| Front Lights | 100 Lux | N / A | N / A | 120 Lux | 40 Lux | 100 Lux | 120 Lux | 100 Lux | Belt drive: 120 lux Chain drive: 2× 70 Lux |
40 Lux | Belt drive: 120 lux Chain drive: 2× 70 Lux |
120 Lux | None (pre-wired for front light) | 80 Lux |
| Rear Light | Integrated into the Racktime luggage carrier | N / A | N / A | Integrated into the Racktime luggage carrier | BÜCHEL Edge | Star Union WD558-2 with brake light function | Büchel Edge | Büchel Edge | Integrated into the mudguards | Büchel Edge with brake light | Integrated into the mudguards | Integrated into the Racktime luggage carrier | N / A | Integrated into the mudguards |
| Net weight | 26,24 kg | 13,51 kg | 13,51 kg | 27,4 kg | 24,59 kg | Comfort Edition 24,7 kg | 26,31 kg | 26,39 kg | Belt drive: 18,4 kg Chain drive: 20,4 kg |
23,5 kg | Belt drive: 19 kg Chain drive: 21,2 kg |
S/M: 29,1 kg M/L: 29,7 kg |
25,70 kg | Belt drive: 19,8 kg Chain drive: 21,8 kg |
| Frame type | low-entry | Diamond | Diamond | low-entry | low-entry | Low-entry, foldable | step-through | Diamond | Diamond | trapeze | trapeze | low-entry | Diamond | low-entry |
| Size | 42 cm | 50 / 56 cm | 50 / 56 cm | 49 cm | 44 cm | 36 cm | 46 cm | 43 cm | 52 / 58 cm | 44 cm | 48.5 cm | 42 / 48 cm | 43 / 48 cm | 48.5 cm |
| stride | 70.5-85.5 cm | 50: 74-90 cm 56: 80-96 cm |
50: 74-90 cm 56: 80-96 cm |
75-97 cm | 68-88 cm | 64-85 cm | 75-93 cm | 72-89 cm | M: 80-102 cm L: 83-107 cm |
70-92 cm | 74-95 cm | S / M: 70-88cm L / XL: 75-95cm |
S / M: 69-87cm L / XL: 72-91cm |
86-104.5 cm |
| Max. permissible total weight | Up to 150 kg | Up to 135 kg | Up to 120 kg | Up to 150 kg | Up to 160 kg | Up to 180 kg | Up to 170 kg | Up to 170 kg | Up to 160 kg | Up to 170 kg | Up to 160 kg | Up to 180 kg | Up to 170 kg | Up to 160 kg |
| frame material | Aluminium 6061 | Deruiz Multivalent Carbon Frame | Deruiz Multivalent Carbon Frame | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 | Aluminium 6061 |
| Rack | Racktime / Load capacity 25 kg / incl. rear light | Not included (compatible mounting points are available on the frame) | Not included | Racktime / Load capacity 25 kg / incl. rear light | Semi-integrated luggage rack / Load capacity 25 kg | Integrated luggage rack / Load capacity 50 kg | Semi-integrated luggage rack / Load capacity 25 kg | Semi-integrated luggage rack / Load capacity 25 kg | Belt drive: Optionally retrofittable Chain drive: Integrated luggage rack / Load capacity 15 kg |
Semi-integrated luggage rack / Load capacity 25 kg | Belt drive: Optionally retrofittable Chain drive: Integrated luggage rack / Load capacity 15 kg |
Racktime / Load capacity 20 kg / incl. rear light | N / A | Integrated luggage rack / Load capacity 15 kg |
| Display | Deruiz LCD with Bluetooth | Deruiz LCD display (without Bluetooth) / double-sided button control | Deruiz LCD display (without Bluetooth) / double-sided button control | Deruiz LCD with Bluetooth | DERUIZ color LCD with Bluetooth | Deruiz LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth | DERUIZ color LCD with Bluetooth |
| App | Deruiz APP | Deruiz APP | Deruiz APP | Deruiz APP | Deruiz Ebike APP | Deruiz APP | Deruiz Ebike APP | Deruiz Ebike APP | Deruiz Ebike APP | Deruiz APP | Deruiz Ebike APP | Deruiz Ebike APP | Deruiz Ebike APP | Deruiz Ebike APP |
